Control block Orbitroly G-OSPC-ON - Zetor URII

Volumetric output (cm³ / rev): 160
P max (bar): 175
T max (bar): 25
L1 (mm): 145
Connection A (BSP): 1/2 "
Weight: 6.16 kg

G-OSPC units have additional integrated valve functions:
- a relief valve
- check valve in L + R
- suction valve in L + R
- non-return valve in P.

About as "Open Center
"Open Center" means that the unit is scheduled for an open system.
In the neutral position, an open connection is established between the pump and the tank.

N "non-reaction"
This means that in the neutral position, the external forces acting on the wheels do not cause a rotating movement on the steering wheel.
